Part numbers
- TX610-A001-1202
Full specifications
| Resolution | 600 dpi |
|---|---|
| Print width | 4 inch |
| Printing method | Direct Thermal / Thermal Transfer |
| Print head type | Flat Head |
| Max printing speed | 102 mm/sec |
| Max printing width | 106 mm |
| Max printing length | 2540 mm |
| Label width | 19 - 112 mm |
| Label length | 3 - 2540 mm |
| Max labels roll diameter | 127 mm |
| Interfaces | RS-232, USB 2.0, USB host for scanner or PC keyboard, Internal Ethernet 10/100 Mbps |
| Memory | 128 MB SDRAM, 128 MB flash memory, Flash memory expansion up to 32 GB |
| Optional | External roll mount, Peel off module, Centronics, KP-200 Plus keyboard display unit, Bluetooth module, External 802.11 b/g/n Wireless, Guillotine cutter (full cut or partial cut) |
| Dimensions | 226 x 200 x 332 mm |
Compatible consumables
Thermal Transfer Ribbons
GPX PREMIUM
- Coated on
- PET film - 12 μm
- Printing temperature
- 110-160 °C
View details →
Thermal Transfer Ribbons
KTR PREMIUM
- Coated on
- PET film - 23,5 μm
- Printing temperature
- 115-125 °C
View details →
Thermal Transfer Ribbons
M110A PREMIUM FLAT HEAD
- Max printing speed
- 10 ips (254 mm/sec)
- Ink melting point
- 84 °C
View details →
Thermal Transfer Ribbons
M110T PREMIUM FLAT HEAD
- Max printing speed
- 10 ips (254 mm/sec)
- Ink melting point
- 84 °C
View details →
