Part numbers
- DA220W-A001-21C2
- DA220W-A001-2102
Full specifications
| Resolution | 203 dpi |
|---|---|
| Print width | 4 inch |
| Printing method | Direct Thermal |
| Print head type | Flat Head |
| Max printing speed | 152.4 mm/sec |
| Max printing width | 108 mm |
| Max printing length | 25400 mm |
| Label width | 19 - 114 mm |
| Label length | 10 - 25400 mm |
| Max labels roll diameter | 127 mm |
| Interfaces | USB 2.0 high speed mode, USB Host, RS-232, Ethernet |
| Memory | 64 MB DRAM, 128 MB flash memory |
| Optional | USB2.0 and Ethernet, Peel-off module, Guillotine cutter (full cut or partial cut), 1.5" adaptor for 1.5" paper core, External roll mount, media OD. 214 mm (8.4") with 25.4 mm (1") core, KP-200 Plus keyboard display unit (serial interface) |
| Dimensions | 172 x 165 x 195 mm |
