Part numbers
- 99-125A013-0002
Full specifications
| Resolution | 203 dpi |
|---|---|
| Print width | 4 inch |
| Printing method | Direct Thermal / Thermal Transfer |
| Print head type | Flat Head |
| Max printing speed | 177.8 mm/sec |
| Max printing width | 108 mm |
| Max printing length | 2286 mm |
| Label width | 20 - 112 mm |
| Label length | 10 - 2286 mm |
| Max labels roll diameter | 127 mm |
| Interfaces | Centronics, USB 2.0, RS-232 |
| Memory | 8 MB SDRAM, 4 MB flash memory, Flash memory expansion up to 4 GB |
| Optional | Internal Ethernet 10/100 Mbps (Factory option), External roll mount, Peel off module, KP-200 Plus keyboard display unit, Bluetooth module, External 802.11 b/g/n Wireless, Guillotine cutter (full cut or partial cut) |
| Dimensions | 200 x 164 x 240 mm |
Compatible consumables
Thermal Transfer Ribbons
GPX PREMIUM
- Coated on
- PET film - 12 μm
- Printing temperature
- 110-160 °C
View details →
Thermal Transfer Ribbons
KTR PREMIUM
- Coated on
- PET film - 23,5 μm
- Printing temperature
- 115-125 °C
View details →
Thermal Transfer Ribbons
M110A PREMIUM FLAT HEAD
- Max printing speed
- 10 ips (254 mm/sec)
- Ink melting point
- 84 °C
View details →
Thermal Transfer Ribbons
M110T PREMIUM FLAT HEAD
- Max printing speed
- 10 ips (254 mm/sec)
- Ink melting point
- 84 °C
View details →
