Key features
- Easy operation with 10.1" (25.65 cm) large screen
- One-key start and stop precise control
- Independent module maintenance is simple
- Automatic cleaning to prevent clogging
- Classic ink circuit is stable and reliable
Full specifications
| Operating system | Embedded Linux security operating system |
|---|---|
| Display screen | 10.1-inch (25.65 cm) color display, industrial touch screen |
| Communication interface | Network port, USB, RS232 |
| Protection level | IP55 |
| Power parameters | Input 100-240V AC |
| Rated power | 150W |
| Memory | 256M |
| Working environment | Temperature 0-45C / Humidity 30-70% Rh |
| Related certification | RoHS, CE, BIS |
| Supported languages | Support more than 40 national languages (Chinese, English, Arabic, Danish, German, Russian, French, Finnish, Korean, Japanese, Spanish, Italian, etc) |
| Machine material | SUS 304 stainless steel |
| Machine specifications | 485mm x 242mm x 664mm (Length*width*height) |
| Net weight | 23kg |
| Main hardware | American TI AM3358 industrial grade CPU, American Xilinx Spartan-6 industrial grade FPGA |
| External interface | Optical sensor, encoder, light alarm, reverse and upside down control, serial number input/output and control, external printing information selection |
