Full specifications
| Vial size | Ø10~25 mm |
|---|---|
| Label length | 15~75 mm |
| Speed | 0~200 vial/min (depending on vial size, shape and label length) |
| Max label roll outer diameter | Ø30 mm |
| Max label roll width | Ø100 mm |
| Min label roll core diameter | Ø76 mm |
| Label requirement | The distance between labels ≥ 3 mm; label thickness > 8 μm; paper base thickness > 5 μm; must have sufficient tensile strength. |
| Total power | 500 W |
| Voltage | 220V / 50~60 Hz |
| Machine size | 1800 × 700 × 1400 mm |
| Weight | 150 kg |
| Direction | Left → Right |
| Environment | No flammable or explosive gases or dust. Humidity ≤85% (no condensation). Temperature: 5 ~ 35°C |
